Description
Descriptions:
This product is well developed and designed independently based on the assimilation of imported products. It adopts PLC control; touch screen and frequency converter technology, which has the quality of stable and easy operation and convenient to adjust the specifications. Multi-point detection and malfunction display functions improve its speed and ability to diagnose the fault and the speed. It has online automatic print batch number function, multi function recognition system, online monitoring and eliminating, automatic stop while the carton gets stuck and alarm function when the machine is in lack of materials, instructions and cartons , so as to guarantee 100% complete products output. Moreover, the machine is equipped with the function of automatic shutting down while is in the condition of less material and overloading. It adopts modular structure, a variety of specifications exchange and no need to change moulds etc. This equipment is the most desirable packing machine in the field, which is widely used in drugs, makeup, food, health care products and stationery commodity etc.
Machine features:
- PLC control, visual touch screen interface and full servo tracking drive
- Multi separation distance and greater flexibility
- Changing specifications is only in need of turning the crank
- International famous brands of electrical originals
- Multi-function online control fault alarm
- Safety interlocking device and full protection alarm function
- Multiple combinations of arbitrary adjustment function
- Visual alarm function
- Modular structure and changing different specification is not in need of changing moulds
- The front part can be used with all kinds of devices and the back can be connected with the line of case packing machine
- The whole machine is made of high quality stainless steel or food grade nylon
Basic Parameters:
Power supply: 380V 50HZ
Total power: 1.5KW
Package specification (Box size): L (65~170) *W (30~800) *H (15~50) mm
Production capacity: 40~80 packs (based on the products)
Air consumption: 5~8L/min
Weight: 1000kg
External dimension: 300mm*1100mm*1650mm
Instruction range: L (80~200) mm*W (90~170) mm
Carton requirement: 250~350g/m2
Instruction requirement: 50~60g/m2
Sealing mode: adhesive spraying or the tongue inserted
Products specification range: The length, width and height should be less than 2~3mm compared with the carton.
Enter box mode: straight line
