Description
Basic parameter
Standard working capacity: <2500 cups/H (based on 150g)
Filling capacity: 40g-250g (can be customized)
Product: Liquid: Yogurt, milk, beverages, sauce and so on.
Filling temperature: Normal: 4-40 oC
90 oC filling system can be supplied for special material
Filling error: ≤±1%
Working efficiency: ≥90 %( Material, packing material, equipment maintenance will affect the efficiency and yield)
Qualification rate of products: ≥99.5%
Cup specifications: Mouth: Ø50-Ø80 (if it is beyond specification, the capacity will decrease accordingly)
Height: 25~140mm
Single step specification: 2 cups
Total power: 3.5kW
Running power: 40%-60%
Motor power: 3kW
Heating power: 1kW
Others: 0.5KW
Air pressure; ≥0.6MPa without oil and water
Air consumption: ≥0.8m³/min
Power supply: 3+N+PE 50Hz 380/220V±10%(3P 5wires) (customized)
Equipment dimensions (about): 2000mm×1400mm×2800mm (L×W×H)
Weight (about): 2.0 tons
Packaging material parameter:
Cap film material: Al+plastic laminated film, paper+plastic
laminated film
Cap film dimension: According to the cup size
Cap film thickness: 0.08 mm -0.15mm
Cap forming film material: PS/PP/PET/PVC
