Description
Automatic Rotary Pre-made Pouch Machine ZK-PF-100
Rapid premade pouch packaging is possible with our duplex fill and seal machine, capable of packing 100 cycles per minute.
Features
8 stations, dual bags
PLC control with touch screen operation
Servo-driven Allen Bradley control platform
Highly durable welded steel frame
Production parameter memory including gripper size, machine speed, sealing temperature, and filling volume
Pouch presence detection – no filling, no sealing
Bag deflation with wire guide or push bars
Automatic feeding station
Two step sealing process guarantees clean sealing
Options
Product filling – can be integrated with multi-head scales, volumetric fillers and auger fillers
Fully interlocked safety guards
Pre-sealing station for liquid or paste
Zipper opening device
Clean-in-place design
Long raised rotary shaft extender for longer bags
Extended bag magazine
Date coding: emboss, hot stamp, inkjet or thermal transfer
Quality control: check weigher, metal detector, X-ray inspection
Dust suction nozzles and dust collector
Product settler
Bag supporter for heavy fills
Ethernet connectivity
Wash down structure (IP65 )
Steam or gas flush
Rotary running clockwise model
Bag rejection system
Collating discharge conveyor
Product information
Duplex Model ZK-PF-100
Number of Stations 8
Number of Lanes 2
Maximum Speed Per Minute (dry cycle) 100 bags per min
Bag Gripping Range (mm) 85-110mm, can be customized
Maximum Bag Length (mm) 350mm
Electrical Requirements 3-Phase, 380V, Approx. 8.5 Kw, 50Hz
Compressed Air: Approx. 900NL/min, 5~6kgf/cm2
