Description

Industry-specific attributes

Packaging Type
Cartons, CANS, Bottles, Barrel, Stand-up Pouch, Bags, Film, Foil, Belt, Pouch, Capsule, case
Packaging Material
Plastic, Paper, Metal, Glass, Wood
Driven Type
Electric
ZONGKI ‘s stretch packaging design is of superior quality and is renowned for its reliability and durability. A wide range of stretch packaging machines, starting from entry-level, cost-effective semi-automatic machines, are suitable for low throughput use. The types of machines range from fully functional semi-automatic high capacity and professional requirements to fully automatic stretch packaging systems, meeting different levels of productivity.
ZONGKI has many years of experience in producing stretch packaging. The quality of all materials and the high technical standards of all mechanical and electronic components, combined with efficient and precise assembly and testing procedures, create high-performance, safe and durable products.

Machine features:

  • CE certification
  • simplified pallet wrapper machine and the light device for wrapping product
  • PCB control and text controller with easy using operation interface and reliable performance quality
  • It can preset wrap-mode, parameter and film tension as needed
  • Sensor detection for object height
  • Black object is in need of a special sensor and special travel switch
  • Inverter controls working speed
  • Soft start and stop function marks machine operation in a stable condition
  • SIAT type anti-stretch system is available
  • High efficiency and energy saving
  • Easy maintenance

Basic information:

Power voltage: 3P AC380V 50/60Hz 1.0KW

Speed of turnplate: 0~10r/min

Dia.of turntable: Φ 1500mm

Mast height: 2400mm

Film: LLDPE film, width≤500mm

Outer diameter≤280mm

Capacity: 1000kg

Max wrapping height: 2000 mm

Package size: L2650 xW1650 xH800mm

G.W/N.W: 700kg/650kg

Noise: ≤75DB

Environment humidity: ≤98%

Temperature: -10~40oC

Working process :

  1. Put the object on the turnplate
  2. Connect the film with the surface of the object
  3. Start the machine, the machine will automatically run and wrap the object
  4. Cut film manually, once the wrapping process finished
