Description
Semi-automatic double side roller labeling machine
Model: ZK-T102
| Labeling accuracy | ±1mm (excluding product and label errors) |
| Labeling speed | 20~35 pieces/min (depending on product and label size) |
| Applicable product size | Length: 40mm ~ 150mm |
| Width: 20mm ~ 120mm | |
| Height: 60mm to 300mm | |
| Applicable label size | Length: 30mm ~ 140mm |
| Width (including the width of the backing paper) : 20mm ~ 175mm (laundry detergent higher label needs to increase the header, the price is calculated separately) | |
| Overall size | About 1350mm*1050mm*1300mm (length × width × height) |
| Applicable power supply | 220V/50HZ |
| Machine weight | About 130Kg |
Basic function
◆ Can attach double labels on both sides of the bottle, (close one of the labeling heads, can attach single side of the bottle)
◆ The adjustable mold can be compatible with bottles of different sizes without changing the mold, and the sliding table can be used to drive the bottle to cover the label, with high labeling accuracy and no bubbles;
◆ Including 8 dimension adjustment seat, label head can be up and down, left and right, front and back, tilt adjustable, very convenient.
◆ Used in all kinds of square flat bottles such as: lubricating oil, car cleaner, glass water, mineral water, mineral water, beverage bottles, laundry liquid bottles, oil smoke net, honey, chemical reagent bottles, shampoo, health wine, nut bottles, cookie bottles, chili oil bottles, chili sauce bottles and other single-sided or double-sided labeling
Optional function
◆ Optional transparent label detection eye, suitable for transparent labels;
◆ Optional ribbon coding machine or thermal transfer coding machine, to print the production date on the label and other functions, coding and labeling synchronous, saving processes;
